P2012DZ
NKK Switches
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSWITCH TOGGLE SPDT 10A 125V
- CategoryToggle Switches
- Datasheet P2012DZ Datasheet
-
ECAD Model
- Share
In Stock: 103
Can ship immediately
Pricing:
- 1$8.96
- 10$8.72145
- 25$8.48518
- 50$8.01378
- 100$7.77808
- 250$7.54238
- 500$6.36388
- 1,000$6.12818
Quote It
Technical Details
- Series:P
- Package:Bulk
- Part Status:Obsolete
- Mounting Type:Panel Mount
- Circuit:SPDT
- Switch Function:On-On
- Current Rating (Amps):10A (AC)
- Voltage Rating - AC:125 V
- Voltage Rating - DC:-
- Actuator Type:Standard Round with Cap
- Actuator Length:19.00mm
- Illumination:Non-Illuminated
- Illumination Type, Color:-
- Illumination Voltage (Nominal):-
- Termination Style:Quick Connect - 0.187" (4.7mm)
- Panel Cutout Dimensions:Circular - 12.50mm Dia
- Bushing Thread:M12 x 1
- Ingress Protection:-
- Features:White Cap
- Operating Temperature:-10°C ~ 85°C
