S5AW
NKK Switches
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSWITCH TOGGLE SPDT 15A 125V
- CategoryToggle Switches
- Datasheet S5AW Datasheet
-
ECAD Model
- Share
In Stock: 164
Can ship immediately
Pricing:
- 1$10.39
Quote It
Technical Details
- Series:S
- Package:Bulk
- Part Status:Active
- Mounting Type:Panel Mount
- Circuit:SPDT
- Switch Function:On-Mom
- Current Rating (Amps):15A (AC), 20A (DC)
- Voltage Rating - AC:125 V
- Voltage Rating - DC:30 V
- Actuator Type:Standard Round
- Actuator Length:17.50mm
- Illumination:Non-Illuminated
- Illumination Type, Color:-
- Illumination Voltage (Nominal):-
- Termination Style:Solder Lug
- Panel Cutout Dimensions:Circular - 12.50mm Dia
- Bushing Thread:M12 x 1
- Ingress Protection:IP67 - Dust Tight, Waterproof
- Features:-
- Operating Temperature:-30°C ~ 70°C
