M2122TCFW02
NKK Switches- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSWITCH TOGGLE DPDT 6A 125V
- CategoryToggle Switches
- Datasheet M2122TCFW02 Datasheet
-
ECAD Model
- Share
In Stock: 154
Can ship immediately
Pricing:
- 1$19.46
Quote It
Technical Details
- Series:M2100
- Package:Bulk
- Part Status:Active
- Mounting Type:Panel Mount
- Circuit:DPDT
- Switch Function:On-On
- Current Rating (Amps):6A (AC), 3A (DC)
- Voltage Rating - AC:125 V
- Voltage Rating - DC:30 V
- Actuator Type:Standard Round
- Actuator Length:14.70mm
- Illumination:Illuminated
- Illumination Type, Color:LED, Red/Green
- Illumination Voltage (Nominal):1.7, 2 VDC
- Termination Style:Quick Connect - 0.062" (1.5mm)
- Panel Cutout Dimensions:Circular - 6.50mm Dia
- Bushing Thread:1/4-40
- Ingress Protection:-
- Features:Epoxy Sealed Terminals
- Operating Temperature:-10°C ~ 55°C
