T201SH9AGE
C&K
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSWITCH TOGGLE DPDT 3A 120V
- CategoryToggle Switches
- Datasheet T201SH9AGE Datasheet
-
ECAD Model
- Share
In Stock: 169
Can ship immediately
Pricing:
- 1$9.6966
- 50$9.4658
Quote It
Technical Details
- Series:T
- Package:Bulk
- Part Status:Active
- Mounting Type:Through Hole, Right Angle
- Circuit:DPDT
- Switch Function:On-On
- Current Rating (Amps):3A (AC/DC)
- Voltage Rating - AC:120 V
- Voltage Rating - DC:28 V
- Actuator Type:Standard Round
- Actuator Length:9.40mm
- Illumination:Non-Illuminated
- Illumination Type, Color:-
- Illumination Voltage (Nominal):-
- Termination Style:PC Pin
- Panel Cutout Dimensions:-
- Bushing Thread:Unthreaded
- Ingress Protection:-
- Features:Epoxy Sealed Terminals
- Operating Temperature:-30°C ~ 85°C
