P2022BZ/UC
NKK Switches
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSWITCH TOGGLE DPDT 10A 125V
- CategoryToggle Switches
- Datasheet P2022BZ/UC Datasheet
-
ECAD Model
- Share
In Stock: 191
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:P
- Package:Bulk
- Part Status:Obsolete
- Mounting Type:Panel Mount
- Circuit:DPDT
- Switch Function:On-On
- Current Rating (Amps):10A (AC)
- Voltage Rating - AC:125 V
- Voltage Rating - DC:-
- Actuator Type:Standard Round
- Actuator Length:17.50mm
- Illumination:Non-Illuminated
- Illumination Type, Color:-
- Illumination Voltage (Nominal):-
- Termination Style:Quick Connect - 0.187" (4.7mm)
- Panel Cutout Dimensions:Circular - 12.50mm Dia
- Bushing Thread:M12 x 1
- Ingress Protection:-
- Features:-
- Operating Temperature:-10°C ~ 85°C
