SCS6JTB6EFL1J0FZ6K
Samsung Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionLED LH141A COOL WHITE 6000K SMD
- CategoryLED Lighting - White
- Datasheet SCS6JTB6EFL1J0FZ6K Datasheet
-
ECAD Model
- Share
In Stock: 175
Can ship immediately
Pricing:
- 1$0.21036
- 10,000$0.21036
Quote It
Technical Details
- Series:LH141A
- Package:Tape & Reel (TR)
- Part Status:Not For New Designs
- Color:White, Cool
- CCT (K):6000K
- Flux @ 85°C, Current - Test:-
- Flux @ 25°C, Current - Test:121lm (110lm ~ 131lm)
- Current - Test:350mA
- Voltage - Forward (Vf) (Typ):2.95V
- Lumens/Watt @ Current - Test:117 lm/W
- CRI (Color Rendering Index):68
- Current - Max:1A
- Viewing Angle:120°
- Mounting Type:Surface Mount
- Package / Case:0606 (1616 Metric)
- Supplier Device Package:SMD
- Size / Dimension:0.057" L x 0.057" W (1.46mm x 1.46mm)
- Height - Seated (Max):0.010" (0.25mm)
