MX6AWT-H1-0000-000C50

Technical Details

• Series:XLamp® MX-6
• Package:Tape & Reel (TR)
• Part Status:Active
• Color:White, Cool
• CCT (K):6000K
• Flux @ 85°C, Current - Test:-
• Flux @ 25°C, Current - Test:104lm (100lm ~ 107lm)
• Current - Test:300mA
• Voltage - Forward (Vf) (Typ):3.3V

• Lumens/Watt @ Current - Test:105 lm/W
• CRI (Color Rendering Index):80
• Current - Max:1A
• Viewing Angle:120°
• Mounting Type:Surface Mount
• Package / Case:2-SMD, Gull Wing Exposed Pad
• Supplier Device Package:SMD
• Size / Dimension:0.197" L x 0.197" W (5.00mm x 5.00mm)
• Height - Seated (Max):0.058" (1.48mm)
