MX6AWT-A1-R250-000BE8

Technical Details

• Series:XLamp® MX-6
• Package:Tape & Reel (TR)
• Part Status:Active
• Color:White, Warm
• CCT (K):2700K
• Flux @ 85°C, Current - Test:-
• Flux @ 25°C, Current - Test:97lm (94lm ~ 100lm)
• Current - Test:300mA
• Voltage - Forward (Vf) (Typ):3.3V

• Lumens/Watt @ Current - Test:98 lm/W
• CRI (Color Rendering Index):80 (Typ)
• Current - Max:1A
• Viewing Angle:120°
• Mounting Type:Surface Mount
• Package / Case:2-SMD, Gull Wing Exposed Pad
• Supplier Device Package:SMD
• Size / Dimension:0.197" L x 0.197" W (5.00mm x 5.00mm)
• Height - Seated (Max):0.058" (1.48mm)
