XMLEZW-02-0000-0D0HU340F

Technical Details

• Series:EasyWhite™, XLamp® XM-L
• Package:Tape & Reel (TR)
• Part Status:Active
• Color:White, Neutral
• CCT (K):4000K 4-Step MacAdam Ellipse
• Flux @ 85°C, Current - Test:330lm (320lm ~ 340lm)
• Flux @ 25°C, Current - Test:-
• Current - Test:350mA
• Voltage - Forward (Vf) (Typ):12V

• Lumens/Watt @ Current - Test:79 lm/W
• CRI (Color Rendering Index):80
• Current - Max:1A
• Viewing Angle:115°
• Mounting Type:Surface Mount
• Package / Case:2020 (5050 Metric)
• Supplier Device Package:SMD
• Size / Dimension:0.197" L x 0.197" W (5.00mm x 5.00mm)
• Height - Seated (Max):0.124" (3.15mm)
