XMLBEZ-00-0000-0D00V227H

Technical Details

• Series:Easywhite®, Xlamp® XM-L2
• Package:Tape & Reel (TR)
• Part Status:Active
• Color:White, Warm
• CCT (K):2700K 2-Step MacAdam Ellipse
• Flux @ 85°C, Current - Test:410lm (400lm ~ 420lm)
• Flux @ 25°C, Current - Test:-
• Current - Test:350mA
• Voltage - Forward (Vf) (Typ):12V

• Lumens/Watt @ Current - Test:98 lm/W
• CRI (Color Rendering Index):82 (Typ)
• Current - Max:1A
• Viewing Angle:115°
• Mounting Type:Surface Mount
• Package / Case:2020 (5050 Metric)
• Supplier Device Package:SMD
• Size / Dimension:0.197" L x 0.197" W (5.00mm x 5.00mm)
• Height - Seated (Max):0.124" (3.15mm)
