LZ1-00WW02-0000

Technical Details

• Series:LZ1
• Package:Tape & Reel (TR)
• Part Status:Obsolete
• Color:White, Warm
• CCT (K):2700K ~ 3000K
• Flux @ 85°C, Current - Test:-
• Flux @ 25°C, Current - Test:164lm (146lm ~ 182lm)
• Current - Test:1A
• Voltage - Forward (Vf) (Typ):3.7V

• Lumens/Watt @ Current - Test:44 lm/W
• CRI (Color Rendering Index):85 (Typ)
• Current - Max:1.2A
• Viewing Angle:85°
• Mounting Type:Surface Mount
• Package / Case:4-SMD, No Lead Exposed Pad
• Supplier Device Package:SMD
• Size / Dimension:0.173" L x 0.173" W (4.40mm x 4.40mm)
• Height - Seated (Max):0.102" (2.60mm)
