XHP35B-00-0000-0D0HE20E5

Technical Details

• Series:XLamp® XHP35.2
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Discontinued at Digi-Key
• Color:White, Neutral
• CCT (K):4000K
• Flux @ 85°C, Current - Test:613lm (590lm ~ 635lm)
• Flux @ 25°C, Current - Test:-
• Current - Test:350mA
• Voltage - Forward (Vf) (Typ):11.2V

• Lumens/Watt @ Current - Test:156 lm/W
• CRI (Color Rendering Index):80
• Current - Max:1.05A
• Viewing Angle:135°
• Mounting Type:Surface Mount
• Package / Case:1414 (3535 Metric)
• Supplier Device Package:SMD
• Size / Dimension:0.136" L x 0.136" W (3.45mm x 3.45mm)
• Height - Seated (Max):0.109" (2.78mm)
