0760555605
Woodhead - Molex- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER IMPACT 240POS PCB
- CategoryBackplane Connectors - Specialized
- Datasheet 0760555605 Datasheet
-
ECAD Model
- Share
In Stock: 199
Can ship immediately
Pricing:
- 1$15.49471
- 140$15.4715
Quote It
Technical Details
- Series:Impact 76055
- Package:Tray
- Part Status:Active
- Connector Usage:-
- Connector Type:Header, Male Pins
- Connector Style:Impact, Guide Right
- Number of Positions:240
- Number of Positions Loaded:All
- Pitch:0.053" (1.35mm)
- Number of Rows:15
- Number of Columns:16
- Mounting Type:Through Hole
- Termination:Press-Fit
- Contact Layout, Typical:80 Differential Pairs
- Features:-
- Contact Finish:Gold
- Contact Finish Thickness:30.0µin (0.76µm)
- Color:Black
