1645595-1
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HDR HI SPEED 90POS EDGE MT
- CategoryBackplane Connectors - Specialized
- Datasheet 1645595-1 Datasheet
-
ECAD Model
- Share
In Stock: 183
Can ship immediately
Pricing:
- 1$22.99853
- 1,800$22.21544
Quote It
Technical Details
- Series:Z-PACK HM-Zd
- Package:Tube
- Part Status:Active
- Connector Usage:-
- Connector Type:Header, Male Pins and Blades
- Connector Style:High Speed
- Number of Positions:90
- Number of Positions Loaded:All
- Pitch:0.098" (2.50mm)
- Number of Rows:6
- Number of Columns:10
- Mounting Type:Board Edge, Through Hole, Right Angle
- Termination:Press-Fit
- Contact Layout, Typical:60 Signal, 30 Ground
- Features:Shielded
- Contact Finish:Gold
- Contact Finish Thickness:30.0µin (0.76µm)
- Color:-
