534043-2
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN RCPT HD 540POS PCB
- CategoryBackplane Connectors - Specialized
- Datasheet 534043-2 Datasheet
-
ECAD Model
- Share
In Stock: 141
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:TBC (Twin Beam Connector)
- Package:Bulk
- Part Status:Obsolete
- Connector Usage:-
- Connector Type:Receptacle, Female Sockets
- Connector Style:High Density (HDC, HDI, HPC)
- Number of Positions:540
- Number of Positions Loaded:All
- Pitch:0.100" (2.54mm)
- Number of Rows:4
- Number of Columns:-
- Mounting Type:Through Hole, Right Angle
- Termination:Solder
- Contact Layout, Typical:-
- Features:Mating Guide
- Contact Finish:Gold
- Contact Finish Thickness:30.0µin (0.76µm)
- Color:Black
