1892430-1
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN RCPT MULTI-BEAM 30POS PCB
- CategoryBackplane Connectors - Specialized
- Datasheet 1892430-1 Datasheet
-
ECAD Model
- Share
In Stock: 165
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:MULTI-BEAM XL
- Package:Tray
- Part Status:Obsolete
- Connector Usage:-
- Connector Type:Receptacle, Female Sockets and Blade Sockets
- Connector Style:Multi-Beam
- Number of Positions:30
- Number of Positions Loaded:All
- Pitch:0.100" (2.54mm)
- Number of Rows:4
- Number of Columns:-
- Mounting Type:Through Hole
- Termination:Press-Fit
- Contact Layout, Typical:24 Signal, 4 Power
- Features:Board Lock, Guide Pin
- Contact Finish:Gold
- Contact Finish Thickness:30.0µin (0.76µm)
- Color:-
