796422-5
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTERM BLOCK 5POS 45DEG 5MM PCB
- CategoryTerminal Blocks - Wire to Board
- Datasheet 796422-5 Datasheet
-
ECAD Model
- Share
In Stock: 101
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:Buchanan
- Package:Bulk
- Part Status:Obsolete
- Number of Levels:1
- Positions Per Level:5
- Pitch:0.197" (5.00mm)
- Mating Orientation:45° (135°) Angle with Board
- Current:10 A
- Voltage:300 V
- Wire Gauge:14-22 AWG
- Mounting Type:Through Hole
- Wire Termination:Screw - Leaf Spring, Wire Guard
- Features:Interlocking (Side)
- Color:Blue
