4116R-R2R-103LF
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRES NTWRK 16 RES MULT OHM 16DIP
- CategoryResistor Networks, Arrays
- Datasheet 4116R-R2R-103LF Datasheet
-
ECAD Model
- Share
In Stock: 163
Can ship immediately
Pricing:
- 1$0.665
- 2,000$0.494
Quote It
Technical Details
- Series:4100R
- Package:Tube
- Part Status:Active
- Circuit Type:R2R Ladder
- Resistance (Ohms):10k, 20k
- Tolerance:±2%
- Number of Resistors:16
- Resistor Matching Ratio:-
- Resistor-Ratio-Drift:50ppm/°C
- Number of Pins:16
- Power Per Element:125mW
- Temperature Coefficient:±100ppm/°C
- Operating Temperature:-55°C ~ 125°C
- Applications:-
- Mounting Type:Through Hole
- Package / Case:16-DIP (0.300", 7.62mm)
- Supplier Device Package:16-DIP
- Size / Dimension:0.865" L x 0.300" W (21.97mm x 7.62mm)
- Height - Seated (Max):0.185" (4.69mm)
