4814P-T02-561
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRES ARRAY 13 RES 560 OHM 14SOIC
- CategoryResistor Networks, Arrays
- Datasheet 4814P-T02-561 Datasheet
-
ECAD Model
- Share
In Stock: 151
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:4800P
- Package:Tube
- Part Status:Active
- Circuit Type:Bussed
- Resistance (Ohms):560
- Tolerance:±2%
- Number of Resistors:13
- Resistor Matching Ratio:-
- Resistor-Ratio-Drift:-
- Number of Pins:14
- Power Per Element:80mW
- Temperature Coefficient:±100ppm/°C
- Operating Temperature:-55°C ~ 125°C
- Applications:Automotive AEC-Q200
- Mounting Type:Surface Mount
- Package / Case:14-SOIC (0.220", 5.59mm Width)
- Supplier Device Package:14-SOM
- Size / Dimension:0.390" L x 0.220" W (9.91mm x 5.59mm)
- Height - Seated (Max):0.094" (2.40mm)
