AD8224BCPZ-WP
Linear Technology (Analog Devices, Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC INST AMP 2 CIRCUIT 16LFCSP
- CategoryLinear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
- Datasheet AD8224BCPZ-WP Datasheet
-
ECAD Model
- Share
In Stock: 191
Can ship immediately
Pricing:
- 1$15.74
- 64$14.00204
Quote It
Technical Details
- Series:-
- Package:Tray
- Part Status:Active
- Amplifier Type:Instrumentation
- Number of Circuits:2
- Output Type:Rail-to-Rail
- Slew Rate:2V/µs
- Gain Bandwidth Product:-
- -3db Bandwidth:1.5 MHz
- Current - Input Bias:10 pA
- Voltage - Input Offset:175 µV
- Current - Supply:750µA (x2 Channels)
- Current - Output / Channel:15 mA
- Voltage - Supply, Single/Dual (±):4.5V ~ 36V, ±2.25V ~ 18V
- Operating Temperature:-40°C ~ 85°C
- Mounting Type:Surface Mount
- Package / Case:16-WQFN Exposed Pad, CSP
- Supplier Device Package:16-LFCSP-WQ (4x4)
