LTC3309AMPV#TRMPBF
Linear Technology (Analog Devices, Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC REG BUCK 6A STEP-DOWN
- CategoryPMIC - Voltage Regulators - DC DC Switching Regulators
-
ECAD Model
- Share
In Stock: 149
Can ship immediately
Pricing:
- 1$10.47
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Function:Step-Down
- Output Configuration:Positive
- Topology:Buck
- Output Type:Programmable
- Number of Outputs:1
- Voltage - Input (Min):2.25V
- Voltage - Input (Max):5.5V
- Voltage - Output (Min/Fixed):0.5V
- Voltage - Output (Max):2.25V
- Current - Output:6A
- Frequency - Switching:Up to 3MHz
- Synchronous Rectifier:Yes
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Package / Case:12-VFQFN Exposed Pad
- Supplier Device Package:12-LQFN (2x2)
