IPD50R500CEBTMA1

Technical Details

• Series:CoolMOS™
• Package:Bulk
• Part Status:Active
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):500 V
• Current - Continuous Drain (Id) @ 25°C:7.6A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):13V
• Rds On (Max) @ Id, Vgs:500mOhm @ 2.3A, 13V
• Vgs(th) (Max) @ Id:3.5V @ 200µA

• Gate Charge (Qg) (Max) @ Vgs:18.7 nC @ 10 V
• Vgs (Max):±20V
• Input Capacitance (Ciss) (Max) @ Vds:433 pF @ 100 V
• FET Feature:Super Junction
• Power Dissipation (Max):57W (Tc)
• Operating Temperature:-55°C ~ 150°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:PG-TO252-3
• Package / Case:TO-252-3, DPak (2 Leads + Tab), SC-63
