NTD5865NLT4G
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 60V 46A DPAK
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet NTD5865NLT4G Datasheet
-
ECAD Model
- Share
In Stock: 1,828,190,137
Can ship immediately
Pricing:
- 1$0.76
- 2,500$0.29608
- 5,000$0.27566
- 12,500$0.26545
- 25,000$0.25988
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):60 V
- Current - Continuous Drain (Id) @ 25°C:46A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):4.5V, 10V
- Rds On (Max) @ Id, Vgs:16mOhm @ 20A, 10V
- Vgs(th) (Max) @ Id:2V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:29 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:1400 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):71W (Tc)
- Operating Temperature:-55°C ~ 175°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:DPAK
- Package / Case:TO-252-3, DPak (2 Leads + Tab), SC-63
