FQI10N20CTU
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 200V 9.5A I2PAK
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet FQI10N20CTU Datasheet
-
ECAD Model
- Share
In Stock: 1,158
Can ship immediately
Pricing:
- 1$0.37
Quote It
Technical Details
- Series:QFET®
- Package:Tube
- Part Status:Obsolete
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):200 V
- Current - Continuous Drain (Id) @ 25°C:9.5A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:360mOhm @ 4.75A, 10V
- Vgs(th) (Max) @ Id:4V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:26 nC @ 10 V
- Vgs (Max):±30V
- Input Capacitance (Ciss) (Max) @ Vds:510 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):72W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:I2PAK (TO-262)
- Package / Case:TO-262-3 Long Leads, I²Pak, TO-262AA
