IRF3709ZPBF
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 30V 87A TO220AB
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet IRF3709ZPBF Datasheet
-
ECAD Model
- Share
In Stock: 10,274
Can ship immediately
Pricing:
- 1$0.43
- 10$0.38104
- 100$0.3011
- 500$0.2335
- 1,000$0.18434
Quote It
Technical Details
- Series:HEXFET®
- Package:Bulk
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):30 V
- Current - Continuous Drain (Id) @ 25°C:87A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):-
- Rds On (Max) @ Id, Vgs:6.3mOhm @ 21A, 10V
- Vgs(th) (Max) @ Id:2.25V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:26 nC @ 4.5 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:2130 pF @ 15 V
- FET Feature:-
- Power Dissipation (Max):79W (Tc)
- Operating Temperature:-55°C ~ 175°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:TO-220AB
- Package / Case:TO-220-3
