IRLU3802PBF

Technical Details

• Series:HEXFET®
• Package:Bulk
• Part Status:Active
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):12 V
• Current - Continuous Drain (Id) @ 25°C:84A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):2.8V, 4.5V
• Rds On (Max) @ Id, Vgs:8.5mOhm @ 15A, 4.5V
• Vgs(th) (Max) @ Id:1.9V @ 250µA

• Gate Charge (Qg) (Max) @ Vgs:41 nC @ 5 V
• Vgs (Max):±12V
• Input Capacitance (Ciss) (Max) @ Vds:2.49 pF @ 6 V
• FET Feature:-
• Power Dissipation (Max):88W (Tc)
• Operating Temperature:-55°C ~ 175°C (TJ)
• Mounting Type:Through Hole
• Supplier Device Package:I-PAK
• Package / Case:TO-251-3 Short Leads, IPak, TO-251AA
