N0600N-S17-AY

Technical Details

• Series:-
• Package:Tube
• Part Status:Obsolete
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):60 V
• Current - Continuous Drain (Id) @ 25°C:30A (Ta)
• Drive Voltage (Max Rds On, Min Rds On):-
• Rds On (Max) @ Id, Vgs:36mOhm @ 15A, 4.5V
• Vgs(th) (Max) @ Id:-

• Gate Charge (Qg) (Max) @ Vgs:29.8 nC @ 10 V
• Vgs (Max):-
• Input Capacitance (Ciss) (Max) @ Vds:1.38 pF @ 10 V
• FET Feature:-
• Power Dissipation (Max):2W (Ta), 20W (Tc)
• Operating Temperature:150°C (TJ)
• Mounting Type:Through Hole
• Supplier Device Package:TO-220
• Package / Case:TO-220-3 Isolated Tab
