BSZ035N03MSGATMA1
IR (Infineon Technologies)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 30V 18A/40A 8TSDSON
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet BSZ035N03MSGATMA1 Datasheet
-
ECAD Model
- Share
In Stock: 13,084
Can ship immediately
Pricing:
- 1$1.24
- 5,000$0.52177
- 10,000$0.50215
Quote It
Technical Details
- Series:OptiMOS™
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):30 V
- Current - Continuous Drain (Id) @ 25°C:18A (Ta), 40A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):4.5V, 10V
- Rds On (Max) @ Id, Vgs:3.5mOhm @ 20A, 10V
- Vgs(th) (Max) @ Id:2V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:74 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:5700 pF @ 15 V
- FET Feature:-
- Power Dissipation (Max):2.1W (Ta), 69W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:PG-TSDSON-8
- Package / Case:8-PowerTDFN
