TJ60S04M3L,LXHQ

Technical Details

• Series:U-MOSVI
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• FET Type:P-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):40 V
• Current - Continuous Drain (Id) @ 25°C:60A (Ta)
• Drive Voltage (Max Rds On, Min Rds On):6V, 10V
• Rds On (Max) @ Id, Vgs:6.3mOhm @ 30A, 10V
• Vgs(th) (Max) @ Id:3V @ 1mA

• Gate Charge (Qg) (Max) @ Vgs:125 nC @ 10 V
• Vgs (Max):+10V, -20V
• Input Capacitance (Ciss) (Max) @ Vds:6510 pF @ 10 V
• FET Feature:-
• Power Dissipation (Max):90W (Tc)
• Operating Temperature:175°C
• Mounting Type:Surface Mount
• Supplier Device Package:DPAK+
• Package / Case:TO-252-3, DPak (2 Leads + Tab), SC-63
