FDB6670AL

Technical Details

• Series:PowerTrench®
• Package:Bulk
• Part Status:Obsolete
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):30 V
• Current - Continuous Drain (Id) @ 25°C:80A (Ta)
• Drive Voltage (Max Rds On, Min Rds On):4.5V, 10V
• Rds On (Max) @ Id, Vgs:6.5mOhm @ 40A, 10V
• Vgs(th) (Max) @ Id:3V @ 250µA

• Gate Charge (Qg) (Max) @ Vgs:33 nC @ 5 V
• Vgs (Max):±20V
• Input Capacitance (Ciss) (Max) @ Vds:2.44 pF @ 15 V
• FET Feature:-
• Power Dissipation (Max):68W (Tc)
• Operating Temperature:-65°C ~ 175°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:TO-263AB
• Package / Case:TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
