IPSA70R360P7SAKMA1
IR (Infineon Technologies)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 700V 12.5A TO251-3
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet IPSA70R360P7SAKMA1 Datasheet
-
ECAD Model
- Share
In Stock: 1,722
Can ship immediately
Pricing:
- 1$1.07
- 10$0.94695
- 100$0.7589
- 500$0.59975
- 1,000$0.48399
Quote It
Technical Details
- Series:CoolMOS™ P7
- Package:Tube
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):700 V
- Current - Continuous Drain (Id) @ 25°C:12.5A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:360mOhm @ 3A, 10V
- Vgs(th) (Max) @ Id:3.5V @ 150µA
- Gate Charge (Qg) (Max) @ Vgs:16.4 nC @ 400 V
- Vgs (Max):±16V
- Input Capacitance (Ciss) (Max) @ Vds:517 pF @ 400 V
- FET Feature:-
- Power Dissipation (Max):59.5W (Tc)
- Operating Temperature:-40°C ~ 150°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:PG-TO251-3
- Package / Case:TO-251-3 Short Leads, IPak, TO-251AA
