PSMN4R6-100XS,127

Technical Details

• Series:-
• Package:Tube
• Part Status:Obsolete
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):100 V
• Current - Continuous Drain (Id) @ 25°C:70.4A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):10V
• Rds On (Max) @ Id, Vgs:4.6mOhm @ 15A, 10V
• Vgs(th) (Max) @ Id:4V @ 1mA

• Gate Charge (Qg) (Max) @ Vgs:153 nC @ 10 V
• Vgs (Max):±20V
• Input Capacitance (Ciss) (Max) @ Vds:9.9 pF @ 50 V
• FET Feature:-
• Power Dissipation (Max):63.8W (Tc)
• Operating Temperature:-55°C ~ 175°C (TJ)
• Mounting Type:Through Hole
• Supplier Device Package:TO-220F
• Package / Case:TO-220-3 Full Pack, Isolated Tab
