IPB80P03P4L04ATMA2

Technical Details

• Series:Automotive, AEC-Q101, OptiMOS®-P2
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• FET Type:P-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):30 V
• Current - Continuous Drain (Id) @ 25°C:80A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):-
• Rds On (Max) @ Id, Vgs:4.4mOhm @ 80A, 10V
• Vgs(th) (Max) @ Id:2V @ 253µA

• Gate Charge (Qg) (Max) @ Vgs:160 nC @ 10 V
• Vgs (Max):+5V, -16V
• Input Capacitance (Ciss) (Max) @ Vds:11300 pF @ 25 V
• FET Feature:-
• Power Dissipation (Max):137W (Tc)
• Operating Temperature:-55°C ~ 175°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:PG-TO263-3-2
• Package / Case:TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
