IPW60R280C6FKSA1
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionPFET, 13.8A I(D), 600V, 0.28OHM,
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet IPW60R280C6FKSA1 Datasheet
-
ECAD Model
- Share
In Stock: 17,946
Can ship immediately
Pricing:
- 1$1.36
- 10$1.22253
- 240$1.01676
- 720$0.83835
- 1,200$0.71942
Quote It
Technical Details
- Series:CoolMOS™
- Package:Bulk
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):600 V
- Current - Continuous Drain (Id) @ 25°C:13.8A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:280mOhm @ 6.5A, 10V
- Vgs(th) (Max) @ Id:3.5V @ 430µA
- Gate Charge (Qg) (Max) @ Vgs:43 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:950 pF @ 100 V
- FET Feature:-
- Power Dissipation (Max):104W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:PG-TO247-3
- Package / Case:TO-247-3
