IQE013N04LM6ATMA1
IR (Infineon Technologies)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 40V 31A/205A 8TSON
- CategoryTransistors - FETs, MOSFETs - Single
-
ECAD Model
- Share
In Stock: 10,024
Can ship immediately
Pricing:
- 1$2.7
Quote It
Technical Details
- Series:OptiMOS™
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):40 V
- Current - Continuous Drain (Id) @ 25°C:31A (Ta), 205A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):-
- Rds On (Max) @ Id, Vgs:1.35mOhm @ 20A, 10V
- Vgs(th) (Max) @ Id:2V @ 51µA
- Gate Charge (Qg) (Max) @ Vgs:55 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:3900 pF @ 20 V
- FET Feature:-
- Power Dissipation (Max):2.5W (Ta), 107W (Tc)
- Operating Temperature:-55°C ~ 175°C (TJ)
- Mounting Type:Surface Mount, Wettable Flank
- Supplier Device Package:PG-TSON-8-4
- Package / Case:8-PowerTDFN
