IRFU2405PBF
IR (Infineon Technologies)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 55V 56A IPAK
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet IRFU2405PBF Datasheet
-
ECAD Model
- Share
In Stock: 14,826
Can ship immediately
Pricing:
- 1$1.48
- 10$1.31244
- 100$1.03727
- 500$0.8044
- 1,000$0.63507
Quote It
Technical Details
- Series:HEXFET®
- Package:Tube
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):55 V
- Current - Continuous Drain (Id) @ 25°C:56A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:16mOhm @ 34A, 10V
- Vgs(th) (Max) @ Id:4V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:110 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:2430 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):110W (Tc)
- Operating Temperature:-55°C ~ 175°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:IPAK (TO-251)
- Package / Case:TO-251-3 Short Leads, IPak, TO-251AA
Related Products
N-CHANNEL POWER MOSFET
- 1: $1.48000
N-CHANNEL POWER MOSFET
- 1: $1.48000
N-CHANNEL POWER MOSFET
- 1: $1.48000
MOSFET N-CH 30V 70A TO262AA
