TK155U65Z,RQ

Technical Details

• Series:DTMOSVI
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):650 V
• Current - Continuous Drain (Id) @ 25°C:18A (Ta)
• Drive Voltage (Max Rds On, Min Rds On):10V
• Rds On (Max) @ Id, Vgs:155mOhm @ 9A, 10V
• Vgs(th) (Max) @ Id:4V @ 730µA

• Gate Charge (Qg) (Max) @ Vgs:29 nC @ 10 V
• Vgs (Max):±30V
• Input Capacitance (Ciss) (Max) @ Vds:1635 pF @ 300 V
• FET Feature:-
• Power Dissipation (Max):150W (Tc)
• Operating Temperature:150°C
• Mounting Type:Surface Mount
• Supplier Device Package:TOLL
• Package / Case:8-PowerSFN
