STB34NM60N
STMicroelectronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 600V 29A D2PAK
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet STB34NM60N Datasheet
-
ECAD Model
- Share
In Stock: 114
Can ship immediately
Pricing:
- 1$8.12
- 1,000$4.22378
- 2,000$4.06734
Quote It
Technical Details
- Series:MDmesh™ II
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):600 V
- Current - Continuous Drain (Id) @ 25°C:29A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:105mOhm @ 14.5A, 10V
- Vgs(th) (Max) @ Id:4V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:84 nC @ 10 V
- Vgs (Max):±25V
- Input Capacitance (Ciss) (Max) @ Vds:2722 pF @ 100 V
- FET Feature:-
- Power Dissipation (Max):250W (Tc)
- Operating Temperature:150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:D2PAK
- Package / Case:TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
