NVBG040N120SC1
ON Semiconductor- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTRANS SJT N-CH 1200V 60A D2PAK-7
- CategoryTransistors - FETs, MOSFETs - Single
-
ECAD Model
- Share
In Stock: 315
Can ship immediately
Pricing:
- 1$15.59
Quote It
Technical Details
- Series:Automotive, AEC-Q101
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- FET Type:N-Channel
- Technology:SiC (Silicon Carbide Junction Transistor)
- Drain to Source Voltage (Vdss):1200 V
- Current - Continuous Drain (Id) @ 25°C:60A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):20V
- Rds On (Max) @ Id, Vgs:56mOhm @ 35A, 20V
- Vgs(th) (Max) @ Id:4.3V @ 10mA
- Gate Charge (Qg) (Max) @ Vgs:106 nC @ 20 V
- Vgs (Max):+25V, -15V
- Input Capacitance (Ciss) (Max) @ Vds:1789 pF @ 800 V
- FET Feature:-
- Power Dissipation (Max):357W (Tc)
- Operating Temperature:-55°C ~ 175°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:D2PAK-7
- Package / Case:TO-263-8, D²Pak (7 Leads + Tab), TO-263CA
