PMN55LN,135

Technical Details

• Series:TrenchMOS™
• Package:Bulk
• Part Status:Obsolete
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):20 V
• Current - Continuous Drain (Id) @ 25°C:4.1A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):4.5V, 10V
• Rds On (Max) @ Id, Vgs:65mOhm @ 2.5A, 10V
• Vgs(th) (Max) @ Id:2V @ 1mA

• Gate Charge (Qg) (Max) @ Vgs:13.1 nC @ 10 V
• Vgs (Max):±15V
• Input Capacitance (Ciss) (Max) @ Vds:500 pF @ 20 V
• FET Feature:-
• Power Dissipation (Max):1.75W (Tc)
• Operating Temperature:-55°C ~ 150°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:6-TSOP
• Package / Case:SC-74, SOT-457
