FDD8447L-F085
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 40V 50A DPAK
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet FDD8447L-F085 Datasheet
-
ECAD Model
- Share
In Stock: 16,928
Can ship immediately
Pricing:
- 1$0.42
- 2,500$0.42
- 5,000$0.399
- 12,500$0.384
- 25,000$0.38182
Quote It
Technical Details
- Series:Automotive, AEC-Q101, PowerTrench®
- Package:Bulk
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):40 V
- Current - Continuous Drain (Id) @ 25°C:50A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):4.5V, 10V
- Rds On (Max) @ Id, Vgs:8.5mOhm @ 14A, 10V
- Vgs(th) (Max) @ Id:3V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:52 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:1.97 pF @ 20 V
- FET Feature:-
- Power Dissipation (Max):65W (Tc)
- Operating Temperature:-55°C ~ 175°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:D-PAK (TO-252)
- Package / Case:TO-252-3, DPak (2 Leads + Tab), SC-63
