NTMS4802NR2G
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 30V 11.1A 8SOIC
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet NTMS4802NR2G Datasheet
-
ECAD Model
- Share
In Stock: 5,414
Can ship immediately
Pricing:
- 1$0.44
- 2,500$0.44
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):30 V
- Current - Continuous Drain (Id) @ 25°C:11.1A (Ta)
- Drive Voltage (Max Rds On, Min Rds On):4.5V, 10V
- Rds On (Max) @ Id, Vgs:4mOhm @ 18A, 10V
- Vgs(th) (Max) @ Id:2.5V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:36 nC @ 4.5 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:5.3 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):910mW (Ta)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:8-SOIC
- Package / Case:8-SOIC (0.154", 3.90mm Width)
