IRLML2244TRPBF
IR (Infineon Technologies)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET P-CH 20V 4.3A SOT23
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet IRLML2244TRPBF Datasheet
-
ECAD Model
- Share
In Stock: 2,000
Can ship immediately
Pricing:
- 1$0.51
- 3,000$0.12521
- 6,000$0.11834
- 15,000$0.11147
- 30,000$0.10323
- 75,000$0.09979
Quote It
Technical Details
- Series:HEXFET®
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- FET Type:P-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):20 V
- Current - Continuous Drain (Id) @ 25°C:4.3A (Ta)
- Drive Voltage (Max Rds On, Min Rds On):2.5V, 4.5V
- Rds On (Max) @ Id, Vgs:54mOhm @ 4.3A, 4.5V
- Vgs(th) (Max) @ Id:1.1V @ 10µA
- Gate Charge (Qg) (Max) @ Vgs:6.9 nC @ 4.5 V
- Vgs (Max):±12V
- Input Capacitance (Ciss) (Max) @ Vds:570 pF @ 16 V
- FET Feature:-
- Power Dissipation (Max):1.3W (Ta)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:Micro3™/SOT-23
- Package / Case:TO-236-3, SC-59, SOT-23-3
