IPZ40N04S58R4ATMA1
IR (Infineon Technologies)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 40V 40A 8TSDSON-32
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet IPZ40N04S58R4ATMA1 Datasheet
-
ECAD Model
- Share
In Stock: 7,346
Can ship immediately
Pricing:
- 1$0.85
- 5,000$0.32834
- 10,000$0.31618
- 25,000$0.30955
Quote It
Technical Details
- Series:Automotive, AEC-Q101, OptiMOS™
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):40 V
- Current - Continuous Drain (Id) @ 25°C:40A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):7V, 10V
- Rds On (Max) @ Id, Vgs:8.4mOhm @ 20A, 10V
- Vgs(th) (Max) @ Id:3.4V @ 10µA
- Gate Charge (Qg) (Max) @ Vgs:13.7 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:771 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):34W (Tc)
- Operating Temperature:-55°C ~ 175°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:PG-TSDSON-8-32
- Package / Case:8-PowerTDFN
