IPB65R110CFDATMA1
IR (Infineon Technologies)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 650V 31.2A D2PAK
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet IPB65R110CFDATMA1 Datasheet
-
ECAD Model
- Share
In Stock: 1,147
Can ship immediately
Pricing:
- 1$6.3
- 1,000$3.45443
- 2,000$3.2817
Quote It
Technical Details
- Series:CoolMOS™
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):650 V
- Current - Continuous Drain (Id) @ 25°C:31.2A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:110mOhm @ 12.7A, 10V
- Vgs(th) (Max) @ Id:4.5V @ 1.3mA
- Gate Charge (Qg) (Max) @ Vgs:118 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:3240 pF @ 100 V
- FET Feature:-
- Power Dissipation (Max):277.8W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:D²PAK (TO-263AB)
- Package / Case:TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
