IMZ120R090M1HXKSA1

Technical Details

• Series:CoolSiC™
• Package:Tube
• Part Status:Active
• FET Type:N-Channel
• Technology:SiCFET (Silicon Carbide)
• Drain to Source Voltage (Vdss):1.2 kV
• Current - Continuous Drain (Id) @ 25°C:26A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):15V, 18V
• Rds On (Max) @ Id, Vgs:117mOhm @ 8.5A, 18V
• Vgs(th) (Max) @ Id:5.7V @ 3.7mA

• Gate Charge (Qg) (Max) @ Vgs:21 nC @ 18 V
• Vgs (Max):+23V, -7V
• Input Capacitance (Ciss) (Max) @ Vds:707 pF @ 800 V
• FET Feature:-
• Power Dissipation (Max):115W (Tc)
• Operating Temperature:-55°C ~ 175°C (TJ)
• Mounting Type:Through Hole
• Supplier Device Package:PG-TO247-4-1
• Package / Case:TO-247-4
