IXFN170N65X2

Technical Details

• Series:HiPerFET™
• Package:Tube
• Part Status:Active
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):650 V
• Current - Continuous Drain (Id) @ 25°C:170A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):10V
• Rds On (Max) @ Id, Vgs:13mOhm @ 85A, 10V
• Vgs(th) (Max) @ Id:5V @ 8mA

• Gate Charge (Qg) (Max) @ Vgs:434 nC @ 10 V
• Vgs (Max):±30V
• Input Capacitance (Ciss) (Max) @ Vds:27000 pF @ 25 V
• FET Feature:-
• Power Dissipation (Max):1170W (Tc)
• Operating Temperature:-55°C ~ 150°C (TJ)
• Mounting Type:Chassis Mount
• Supplier Device Package:SOT-227B
• Package / Case:SOT-227-4, miniBLOC
