TPS1101D
Texas Instruments
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET P-CH 15V 2.3A 8SOIC
- CategoryTransistors - FETs, MOSFETs - Single
-
ECAD Model
- Share
In Stock: 375
Can ship immediately
Pricing:
- 1$2.68
- 10$2.41828
- 75$2.15921
- 150$1.94328
- 525$1.51143
- 1,050$1.25233
- 2,550$1.20914
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- FET Type:P-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):15 V
- Current - Continuous Drain (Id) @ 25°C:2.3A (Ta)
- Drive Voltage (Max Rds On, Min Rds On):2.7V, 10V
- Rds On (Max) @ Id, Vgs:90mOhm @ 2.5A, 10V
- Vgs(th) (Max) @ Id:1.5V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:11.25 nC @ 10 V
- Vgs (Max):+2V, -15V
- Input Capacitance (Ciss) (Max) @ Vds:-
- FET Feature:-
- Power Dissipation (Max):791mW (Ta)
- Operating Temperature:-40°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:8-SOIC
- Package / Case:8-SOIC (0.154", 3.90mm Width)
