IPP65R190C7FKSA1
IR (Infineon Technologies)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 650V 13A TO220-3
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet IPP65R190C7FKSA1 Datasheet
-
ECAD Model
- Share
In Stock: 374
Can ship immediately
Pricing:
- 1$3.21
- 50$2.59195
- 100$2.33267
- 500$1.81431
- 1,000$1.50327
Quote It
Technical Details
- Series:CoolMOS™ C7
- Package:Tube
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):650 V
- Current - Continuous Drain (Id) @ 25°C:13A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:190mOhm @ 5.7A, 10V
- Vgs(th) (Max) @ Id:4V @ 290µA
- Gate Charge (Qg) (Max) @ Vgs:23 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:1150 pF @ 400 V
- FET Feature:-
- Power Dissipation (Max):72W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:PG-TO220-3
- Package / Case:TO-220-3
