IXFX52N100X
Wickmann / Littelfuse
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 1000V 52A PLUS247
- CategoryTransistors - FETs, MOSFETs - Single
-
ECAD Model
- Share
In Stock: 186
Can ship immediately
Pricing:
- 1$28.02
- 30$23.817
- 120$22.1358
- 510$19.614
Quote It
Technical Details
- Series:HiPerFET™
- Package:Tube
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):1000 V
- Current - Continuous Drain (Id) @ 25°C:52A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:125mOhm @ 26A, 10V
- Vgs(th) (Max) @ Id:6V @ 4mA
- Gate Charge (Qg) (Max) @ Vgs:245 nC @ 10 V
- Vgs (Max):±30V
- Input Capacitance (Ciss) (Max) @ Vds:6725 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):1250W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:PLUS247™
- Package / Case:TO-247-3
